Innuos Zen Mk3
AUDIO OUTPUTS
Digital Output - USB 2.0 supporting USB Audio Class 2, DoP, Native DSD and MQA Dedicated Ethernet Streamer Port
CONNECTIVITY
Ethernet - 2 x rear panel RJ45 – Bridged Gigabit Ethernet
USB - 1x USB 2.0 (DAC), 1x USB 3.0 (Backup)
FORMATS
CD Formats - Red Book
Disc Compatibility - CD, CD-R, CD-RW
Audio format for stored CDs - FLAC (zero compression), WAV
Audio Formats Supported for streaming and playing - WAV, AIFF, FLAC, ALAC, AAC, MP3, MQA (with supported DACs)
SAMPLE RATES
Sample Rates - 44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4KHz. 192kHz, 352.8KHz, 384KHz , up to DSD128 via DoP, Native DSD on selected DACs
Bit Depths - 16bit, 24bit, 32bit
USER CONTROL INTERFACES
Web Interface - Web Browsers from iOS, Android (4.0 and up) or up-to-date Windows and OS X browsers
Mobile - App for iPhone/iPad, Android and Windows 10
HARDWARE
CD/DVD drive - TEAC Slot-loading drive
Hard Drive - 1TB WD Red HDD
CPU - Intel Quad Core N4200
Memory - 8GB DDR3 Low-Voltage RAM (4GB Dedicated for RAM Playback)
STREAMING AND CD STORAGE
UPnP/DLNA - Integrated UPnP Server
Streaming Services - Qobuz, Spotify Connect, Tidal, Internet Radio
Roon Compatibilit - Roon Core and Roon Bridge
Average CD Storage Time5 - minutes
CD Metadata - FreeDB, MusicBrainz, Discogs, GD3
Compatible Music Systems - Sonos Multi-room Wireless Music System, DLNA/UPnP compatible devices, USB DACs complying to USB Audio Class 2, USB DACs supporting DSD over DoP protocol, Selected USB DACs supporting Native DSD
REQUIREMENTS
Network - Internet connection to access album metadata when storing CDs, Internet Radio, Streaming Services and software updates, Network router with at least one available ethernet port, Premium subscription required for some streaming services such as Spotify, Qobuz and Tidal
Recommended App (USB Connection Only) - iPeng 9 (iOS), OrangeSqueeze (Android), Squeeze Control (Windows 10)
POWER
Mains Supply - 230V AC / 115V AC - Internal Dual-Linear Power Supply
Power Consumption - 12W when idle, 15W peak
